SKU:100Slim
VoltX
VoltX 12V 100Ah Slim Battery
VoltX 12V 100Ah Slim Battery
Couldn't load pickup availability
The VoltX 12V 100Ah Slim Premium is one of our lightest batteries in the range. At 12kgs, this is perfect for RVs and boats, especially with a design that can easily fit in most spaces.
It has a rugged ABS case with flame retardant material, which encloses grade-A prismatic cells that provide a more stable performance than cylindrical battery cells. Suitable for parallel or series connection, fast-charging, and equipped with a built-in BMS, this power pack incurs a lower total cost of operation during its battery life & delivers better overall reliability.
- Approved in accordance with IEC 62619
Features
Features
Intelligent balancing function
Multiple safety protection
Slimline, space-saving design
Safest lithium battery technology
3 years Australian warranty
Approved in accordance with IEC 62619
Specifications
Specifications
Dimensions:395(L) x 110(W) x 297(H)mm
Weight:12kgs
Nominal Voltage:12.8V
Nominal Capacity:100Ah
Charging Voltage:14.2-14.6v
Rated Energy:1280Wh
Rated Discharge Current:100AMax.
Discharge Current:100AMax.
Discharge Current 5 sec:200A
Approx Life Cycles:4000
Absorption Voltage:13.8V
Float Voltage:13.5V
Overcharge Protection:14.6V
Overcharge Recovery:14.2V
Overdischarge Protection:11.2V
Overdischarge Recovery:11.6V
Cell Grouping:4S1P
Working Temperature Range:
Charge: 0°C to 45°C
Discharge: -25°C to 65°C
Storage Temperature:-10℃ to 50℃
Battery Cells:Prismatic
Case Material:ABS Plastic
Parallel Connection:Yes, max 6 batteries
Series Connection:Yes, max 6 batteries
Warranty in Years:3
Fitting
Fitting
Battery requires a secure fitting position. Battery box is recommended.
